Natural Oak
3D Assembly Manual
JYSK GEDSTED Wall Cabinet
14 animated assembly steps, 16 interactive 360° parts & hardware, X-ray joinery view, exploded view, and 8 cabinet finishes.
14 steps · X-Ray joinery · 16 parts in 360° · 8 finishes
3D Assembly Manual Playground
Try our 3D assembly manuals
Replace static paper diagrams with interactive 3D instructions buyers can orbit, scrub step by step, inspect in X-ray, and match to the exact finish and hinge side they bought.
- 14 steps
- Animated step-by-step assembly sequence
- 16 parts
- Boards & hardware to inspect in 360°
- 8 finishes
- Veneers & matte lacquers in real time
JYSK GEDSTED Wall Cabinet
· SKU 3670653 · 550 × 550 × 330 mmUse ← / → arrow keys to step · Space to play/pauseOpen fullscreen manual
JYSK GEDSTED · 3D MANUAL
14 steps
Wall cabinet assembly
Inspect the 550 × 550 × 330 mm cabinet in 3D, test the door & finishes, or start the 14-step build.
Built for furniture & hardware brands
What goes into a 3D manual
Every manual is engineered from the actual flat-pack joinery — dowels, cam pins, cam locks, routed grooves, and adjustable hinges — so nothing is left to guesswork.
01 · STEP PLAYER
Zero-layout-shift step timeline & scrubber
Step forward or back, jump to any of the 14 assembly steps, or drag the timeline scrubber to inspect the exact motion of every board and fastener.
02 · X-RAY JOINERY
See dowels, cam pins & cam locks inside the wood
Switch on X-Ray mode or click any hardware callout to dissolve outer panels and see how concealed cam locks, wooden dowels, and Euro hinges engage.
03 · 360° PARTS SHEET
Every board and screw in the box, isolated in 360°
Open the visual parts sheet or click any part pill in the step card to isolate that exact component with millimetre dimensions and material specs.
04 · DUAL CYCLES AO
Studio-baked self & contact ambient occlusion
Pre-baked Cycles self-AO during flat-lay and exploded views blends dynamically into full-cabinet contact shadows as each panel locks into place.
Free pilot buildTurn your hardest assembly manual into 3D
Send us one product and its PDF manual — we'll build an interactive 3D assembly guide you can test with your customers and support team.
- STEP 01
Send your PDF manual & CAD / SKU
Share your existing assembly PDF, bill of materials, and CAD or reference photos for one product.
- STEP 02
We model every board & fastener
Our team builds the 3D parts, hardware library, animated step choreography, and Cycles AO bakes.
- STEP 03
Embed or link via QR code in ~2 weeks
Drop the interactive 3D manual onto your product page and print a QR code on the box insert.
- STEP 04
Fewer support tickets & returns
Customers assemble with confidence in any finish, hinge orientation, or language.
